PLC Module
The KQ330 Module is a power line communication module. It is designed to communicate between two devices directly through power line (e.g 220V power line) without any extra components. It has Interface baud rate of 9600bps. It is designed with high withstand voltage and anti high pressure shock for communication between two devices. It uses regulated 5V, 500mA power supply. It is suitable for either residential (at-home) or commercial (offices, apartments, hotels, warehouses) network applications, which utilize power lines.
Availability: In Stock
| Name | KQ330 Power Line Communication Module |
| Working Rate | 120~135KHZ |
| Interface Baud Rate | 9600bps |
| Temperature | -25 Degree~+70 Degree |
| Humidity | 90% |
| Power | DC +5V |
| Receiver Sensitivity | ≤1mV |
| Out Of Band Inhibition Ability | ≥ 60 dB |
| Bandwidth | ≤10 KHZ |
| Insulation Resistance | 500V ≥500MΩ |
| Receiver | 11mA |
| Transmitter | 300mA |
