RFID Reader IC
The RFID Reader IC is a RFID Reader MF RC522 Module. It is used in highly integrated 13.56MHz communication card chip to read and write. It has various features like: - Low voltage, Low cost, small size, and Non-contact card chip to read and write and so on. It can be suitable for various applications like: - Smart home project, Voice broadcast access control system, Attendance punch card system and many more.
Availability: In Stock
| Name | RFID Reader IC |
| Operating Voltage Range | 3.3 V |
| Interface Logic Level Chip, Compatible with 3.3 V | Onboard Level Converter |
| Operating Current Range | 13 To 26 mA |
| Idle Current Range | 10 To 13 mA |
| Sleep Current | <80 uA |
| Peak Current | <50 mA |
| Operating Frequency | 13.56 MHz |
| Supported Card Types | Mifare1 S50, Mifare1 S70 MIFARE Ultralight, Mifare Pro, MIFARE DESFire. |
| Data Transfer Rate | (Maximum) 10Mbit/s |
| Working Temperature Range | -20°C To 80°C |
| Storage Temperature Range | -40°C To 85°C |
| Humidity | 5% To 95% |
