HRS998T Mini 5.8Ghz FPV Mini Camera

The HRS998T is a compact and lightweight FPV camera designed for high-quality wireless video transmission. It features a 1/4 inch CMOS sensor delivering 600TVL resolution and supports 48 channels across the 5.8GHz frequency band—ideal for avoiding interference during use.

Equipped with a wide-angle lens offering a 100° field of view and a 120° diagonal FOV, it captures broad, clear visuals. The camera supports both NTSC and PAL video formats, and includes functions like vertical image inversion and horizontal mirroring for flexible installation.

The HRS998T comes with a digital display and user-friendly touch switch or PWM channel selection. Its cloverleaf omnidirectional antenna ensures reliable transmission over various distances.

Sensor: 1/4 inch CMOS
Channels: 48
Resolution: 600TVL
TV system: NTSC / PAL switchable
Modulation type: FM
Channel SEL: touch switch / PWM
Output signal: 12 - 14dB
Frequency control: PLL
All harmonic: -50dBm ( max )
Frequency stability: -100 - 100KHz
Frequency precision: -200 - 200KHz
Channel carrier error: 1dB
Antenna port: 50 ohm
Input format: NTSC / PAL
FOV: 100 degree
DFOV: 120 degree
Supply voltage: 5V - 18V
