4pcs 2212 920KV Brushless Motor + 4pcs 30A Simonk ESC + 2 Pair self-locking propeller four-axis forF450 F550 S500 S550 X525 Quadcopter Multicopter

Product Description

2212 920KV Brushless Motor

- Type : 22 x 12mm

- KV: 920rpm/V

- Voltage: DC 7-12V

- Weight: 53g

30A SimonK RC Brushless ESC:

Highest efficiency 100% N-FET design.

Highest accuracy with Crystal Oscillator (Temperature won't affect the PWM operating range like other cheap ESC's).

No low voltage cutoff, because any cutoff in a multirotor = crash.

No over temp cutoff, because any cutoff in a multirotor = crash.

Super high refresh rate, no buffering of the input signal, resulting in more than 490Hz response rate.

16KHz motor frequency, giving fastest response of the motor, and quietest operation as well (no 8KHz squeal).

Super simple, foolproof operation! Nothing to program other than the throttle range.

Don't buy a 30A multirotor ESC that doesn't meet all these criteria! There are a lot of low quality 30A ESC out there!

ESC Specification

Cont Current: 30A

Burst Current: 35A

BEC Model: Linear mode

BEC Output: 5V2A

Li-ion/Li0poly:2-4S,or Ni-MH/Ni-Cd:4-12NIMH

Weight: 25g

Size: 32*24*7mm


Package Included:

4 x 2212 920KV Brushless Motor (2 CW , 2 CCW )

4 x 30A Simonk esc


2Pair Self Locking Propeller Four Axis F550 six-axis
