25MHZ RIGOL 2 output channels 5 standard waveforms DG1022U (Function Generator)
It adopts advanced DDS technology. It has dual-channel output too.
Availability: Out Of Stock
| Model | DG1022 U |
| Max Output Frequency | 20 MHz (5 MHz Square Wave) |
| Output Channel | 2 |
| Sample Rate | 100 MSa/s |
| Arbitrary Waveform Length of CH1 | 2 pts- 4 kpts |
| Arbitrary Waveform Length of CH2 | 2pts-1kpts |
| Resolution | 1uHz |
| Standard Resolution | USB Host and Device |
It has a 100 MSa/s maximum sampling rate. It has 14 bits vertical accuracy also. It has Output 5 standard waveforms and also it is built-in 48 arbitrary waveforms too. This mini electronic device has Abundant modulation functions: AM, FM, PM, FSK, linear/logarithm sweep, and burst. It has a Built-in high precision and wideband counter, the measurement range: 100 MHz ~ 200 MHz (single channel). This electronic device has Standard configuration interfaces: USB Device & USB Host, and supports U-disc storage. It has unique features too like it Supports remote control by commands, variety of display modes, Clear graphical interface, Support Chinese and English menu and input, Button-help makes information getting easier, File management (support for USB flash device and local storage)
